Title
- Removable LCD control module with multiple communications servers and ATM.
- Built-in Bluetooth for mobile monitoring (Android App is available).
- Replaceable fan design for ease of maintenance.
- Supply load from Grid or PV, even battery is not available.
- Configurable AC/PV output usage timer and prioritization.
- Selectable high-power charging current.
- Selectable input voltage range for home appliances and personal computers.
- Compatible to Utility Mains or generator input.
- Auto restart while AC is recovering.
- Cold start function.
Technical Data
- Model: OG 3.24.
- Rated Power: 3000VA/3000W.
- Parallel: No
Input
- Voltage: 230 VAC.
- Selectable Voltage Range: 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances).
- Frequency Range: 50 Hz/60 Hz (Auto sensing).
Output
- AC Voltage Regulation (Batt. Mode: 230VAC ± 5%.
- Surge Power: 6000VA.
- Efficiency (Peak): 93%.
- Transfer Time: 15 ms (For Personal Computers); 20 ms (For Home Appliances).
- Waveform: Pure sine wave.
Battery
- Battery Voltage: 24 VDC.
- Floating Charge Voltage: 27 VDC.
- Overcharge Protection: 33 VDC.
Solar Charger & AC Charger
- Solar Charger Type: MPPT.
- Maximum PV Array Power: 4000 W.
- MPP Range @ Operating Voltage: 120 VDC ~ 430 VDC.
- Maximum PV Array Open Circuit Voltage: 500 VDC.
- Maximum Solar Charge Current: 80 A.
- Maximum AC Charge Current: 60 A.
- Maximum Charge Current: 80 A.
Physical
- Dimension, D x W x H (mm): 115 x 300 x 400.
- Net Weight (kgs): 9.
- Communication Interface: USB/RS232/RS485/Bluetooth/Dry contact.
Included in box
- Inverter x 1
- User manual x 1
- RS232 Communication cable x 1
- Software CD x 1
- DC Fuse x 1
